1. DLLA150P848 Injector Nozzle’s Basic Information

Title	Common Rail DLLA150P848 Injector Nozzle China Made New	Brand
SKU1	G1X9LLA150P848	XINGMA
SKU2	X90000B2B50P848	XINGMA

2.  DLLA150P848 Injector Nozzle’s Common Written Part Number

Injector Nozzle Order Number	Injector Nozzle Engraved Number
0433171576	DLLA150P848

3.  DLLA150P848 Injector Nozzle’s Application Information for Injectors

（1） DLLA150P848 Injector Nozzle’s Application for Injectors Part Number

Injector Part Number	Series	System Pressure	Re-manufactured Part Number	System Pressure
0 414 701 008	PDE100S2007		0 986 441 008
0 414 701 019	PDE100S2016		0 986 441 108
0 414 701 045	PDE100S2034		0 986 441 015
0 414 701 057	N2 TB SC E3		0 986 441 115
0 414 701 067	N2 BB-DR SC DI-E3
0 414 701 082	N2 TB-ZP SC DC-E3
0 414 701 097	PDE 100 S 2016
0 414 701 027	PDE100S2016

（2） DLLA150P848 Xingma Injector Nozzle’s Car Model Matching Information

Injector Part Number	Car Model	OE Number	OE Number	OE Number	OE Number
0 414 701 008	SCANIA	1409193	1455861	1529751	1497386
0 414 701 019	SCANIA	1440579
0 414 701 045	SCANIA	1805343
0 414 701 057	SCANIA	1529751	1497386	1409193	1455861
0 414 701 067
0 414 701 082	SCANIA	1440579
0 414 701 097

4. DLLA150P848 Injector Nozzle’s Specifications and Dimensions Parameters

Injector Nozzle Size： 6 cm*1.5cm *1.5 cm

Injector Nozzle Barrel Dimensions：7 cm *2 cm *2 cm

Single Injector Nozzle Weight：0.03kg

Injector Nozzle 10 PCS Per Box：10 cm *8 cm *4cm

Injector Nozzle Weight 10 PCS Per Box ：0.3kg

Injector Nozzle Quality：China Made New Injector Nozzle

Injector Nozzle MOQ：10 PCS

5. DLLA150P848 Injector Nozzle Quality Control

（1）Injector Nozzle Testing

All parts of the injector nozzle are subjected to precision testing, high temperature testing, low temperature testing, withstand pressure testing, leakage testing, durability testing, and various working conditions testing.

（2）Injector Nozzle Inspection

The factory inspection of the injector nozzle is undergone full inspection, random inspection, and batch inspection three inspections. Different brands of test benches are used to test the same injector nozzle for a total of no less than three times for factory inspection, and the fuel injector installation testing environment are progressed in dust-free workshop.

（3）Injector Nozzle Installation

When matching the valve cap and valve steam, Shumatt strictly complies with the standard of valve cap and valve stem clearance technical indicators to ensure that each valve assembly meets the factory standards and use standards.

6. DLLA150P848 Injector Nozzle’s Customized Service

（1）Injector Nozzle’s Customized Service：Meet the customized needs of OEM manufacturers for shell lettering (logo, nozzle part number, date and series number), nozzle without lettering, nozzle tube, nozzle box customized etc.

（2）Injector Nozzle’s Customized Service Quantity Requirements：

The purchased of Customized injector nozzle’s shell lettering or without lettering are no less than 100 pieces.

The purchased of Customized injector nozzle tubes are no less than 2000-3000 pieces.

The purchased of customized injector nozzle boxes are no less than 1000 pieces.

Customized products involve the need of specify logo, the OEM manufacturer needs to provide trademark authorization and the sample of logo image file.

Once the customized injector nozzle is sold, it can’t be returned or exchanged if there is no quality problems.

7. DLLA150P848 Injector Nozzle’s Shipping Packing

Domestic express packaging：Usually wrapped in waterproof scotch tape, such as picture No.2.

International express packaging：Wrapped with waterproof yellow tape After wrapping the black protective film, such as picture No. 3.

Pallet Shipping：Use fumigation free and recycling trays that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties for the outside, such as picture No. 4,

Also, the products can be packaged according to customers’ requirements.

• The packing tray is made of plastic and can be recycled.
• Transparent tape, yellow tape, black wrapping protective film, white wrapping protective film are non-degradable materials, please dispose of them properly.

Minors are prohibited from using transparent tape, yellow tape, black wrapping protective film, and white wrapping protective film to avoid personal injury

Pic No.1

International express packaging：

Wrapped with yellow tape after wrapping black protective film





Pic No.2

Pallet Shipping：Use pallet that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties
