1. DSLA144P890+ Injector Nozzle’s Basic Information

Title	Common Rail DSLA144P890+ Injector Nozzle China Made New	Brand
SKU1	G1X9SLA144P890	XINGMA

2.  DSLA144P890+ Injector Nozzle’s Common Written Part Number

Injector Nozzle Order Number	Injector Nozzle Engraved Number
0433175250	DSLA144P890+

3.  DSLA144P890+ Injector Nozzle’s Application Information for Injectors

• DSLA144P890+ InjectorNozzle’s Application for Injectors Part Number

Injector Part Number	Injector Series	System Pressure	Re-manufactured Part Number	System Pressure
0 445 110 036	CRI1-13	1350	0 986 435 013
			0 986 435 014	1350
			0 986 435 015

（2） DSLA144P890+ Xingma Injector Nozzle’s Car Model Matching Information

Injector Part Number	Car Number	OE Number	OE Number	OE Number	OE Number	OE Number
0 445 110 036	CITROEN	96 282 404	96 364 040	1980 73	1980 74	96 533 448
		1980 H5	1980 H6	96 372 779
	FIAT	K9638444780	K9638444880	K9638444980	K9653345780	K9653345880
		9638444780	9638444880	9638444980	9653345780	9653345880
	LANCIA	9638444780	9638444880	9638444980	9653345780	9653345880
		K9638444780	K9638444880	K9638444980	K9653345780	K9653345880
	PEUGEOT	96 282 404	96 533 457	96 533 458	96 533 448	96 533 459
		96 372 779	1980 H5	96 384 447	96 364 040	96 384 448
		96 384 449	1980 73	1980 74	1980 75
	PSA (PEUGEOT S.A.)	1980 H5	96 533 44880

4. DSLA144P890+ Injector Nozzle’s Specifications and Dimensions Parameters

Injector Nozzle Size： 6 cm*1.5cm *1.5 cm

Injector Nozzle Barrel Dimensions：7 cm *2 cm *2 cm

Single Injector Nozzle Weight：0.03kg

Injector Nozzle 10 PCS Per Box：10 cm *8 cm *4cm

Injector Nozzle Weight 10 PCS Per Box ：0.3kg

Injector Nozzle Quality：China Made New Injector Nozzle

Injector Nozzle MOQ：10 PCS

5. DSLA144P890+ Injector Nozzle Quality Control

（1）Injector Nozzle Testing

All parts of the injector nozzle are subjected to precision testing, high temperature testing, low temperature testing, withstand pressure testing, leakage testing, durability testing, and various working conditions testing.

（2）Injector Nozzle Inspection

The factory inspection of the injector nozzle is undergone full inspection, random inspection, and batch inspection three inspections. Different brands of test benches are used to test the same injector nozzle for a total of no less than three times for factory inspection, and the fuel injector installation testing environment are progressed in dust-free workshop.

（3）Injector Nozzle Installation

When matching the valve cap and valve steam, Shumatt strictly complies with the standard of valve cap and valve stem clearance technical indicators to ensure that each valve assembly meets the factory standards and use standards.

6. DSLA144P890+ Injector Nozzle’s Customized Service

（1）Injector Nozzle’s Customized Service：Meet the customized needs of OEM manufacturers for shell lettering (logo, nozzle part number, date and series number), nozzle without lettering, nozzle tube, nozzle box customized etc.

（2）Injector Nozzle’s Customized Service Quantity Requirements：

The purchased of Customized injector nozzle’s shell lettering or without lettering are no less than 100 pieces.

The purchased of Customized injector nozzle tubes are no less than 2000-3000 pieces.

The purchased of customized injector nozzle boxes are no less than 1000 pieces.

Customized products involve the need of specify logo, the OEM manufacturer needs to provide trademark authorization and the sample of logo image file.

Once the customized injector nozzle is sold, it can’t be returned or exchanged if there is no quality problems.

7. DSLA144P890+ Injector Nozzle’s Shipping Packing

Domestic express packaging：Usually wrapped in waterproof scotch tape, such as picture No.2.

International express packaging：Wrapped with waterproof yellow tape After wrapping the black protective film, such as picture No. 3.

Pallet Shipping：Use fumigation free and recycling trays that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties for the outside, such as picture No. 4,

Also, the products can be packaged according to customers’ requirements.

• The packing tray is made of plastic and can be recycled.
• Transparent tape, yellow tape, black wrapping protective film, white wrapping protective film are non-degradable materials, please dispose of them properly.

Minors are prohibited from using transparent tape, yellow tape, black wrapping protective film, and white wrapping protective film to avoid personal injury

Pic No.1

International express packaging：

Wrapped with yellow tape after wrapping black protective film





Pic No.2

Pallet Shipping：Use pallet that meet export requirements, and use white wrapping protective film to wrap and bind with cable ties
